Short Description:

Polyurethane-edged rock wool (or glass wool) panels feature a core of non-combustible rock wool or glass wool and facings of color-coated galvanized or Al-Zn coated steel, with polyurethane foam sealing the edges. These panels are manufactured on a continuous production line imported from Germany. The polyurethane edge-sealing process effectively overcomes the tendency of rock wool and glass wool to absorb moisture and degrade, perfectly combining the fire resistance, thermal insulation, and sound absorption properties of the core material with the sealing capabilities, high strength, and moisture/water resistance of polyurethane. These panels are widely used in steel-structure buildings, such as industrial plants, power projects, automotive showrooms, cement warehouses, and logistics centers.

Product Detail

Product Tags

Performance Features

  1. Excellent Sealing Performance: The production line’s dual-sided polyurethane edge-sealing process effectively prevents the rock wool or glass wool core from absorbing moisture; superior thermal insulation and sound absorption properties help reduce energy consumption and extend service life.
  2. Outstanding Fire Resistance: The combustion performance of the rock wool core meets the GB8624 Class A standard.
  3. Optimized Connection Method: Roof panels utilize a concealed fastener system, eliminating leakage risks at joints and reducing the number of accessories required.
  4. Aesthetic Appeal: The joint design complies with European standards, featuring a flat, smooth surface and tight, reliable connections that effectively prevent thermal bridging.
  5. Scratch Protection: A PE protective film can be applied during production to prevent scratches or damage to the steel coating during transport and installation.
ItemTongue-and-Groove PanelExterior Wall PanelRoof Panel
Effective Width1120 mm1000 mm1000 mm
Expanded Width1200 mm1200 mm1200 mm
Panel Thickness0.4 – 0.8 mm0.4 – 0.8 mm0.4 – 0.8 mm
Panel TypeColor-coated sheet, Galvanized / Aluzinc sheet, Stainless steel sheet
Panel CoatingPVDF (polyvinylidene fluoride), HDP (high-durability polyester), SMP (silicone-modified polyester), PE (polyester)
Panel Metallic CoatingZinc coating, Aluzinc coating
Recommended ManufacturersBlue Scope, Baosteel, Yieh Phui (Yehui), Guanzhou, etc.
Standard ColorsWhite-grey, Sea blue
Core MaterialWater-repellent rockwoolWater-repellent glasswoolWater-repellent glasswool
Density≥ 120 kg/m³≥ 64 kg/m³≥ 64 kg/m³
Thermal Conductivity≤ 0.044 W/(m·K)≤ 0.042 W/(m·K)≤ 0.042 W/(m·K)
Water Repellency≥ 98 %≥ 99 %≥ 99 %
Fire Retardant GradeAAA
Overall Panel Thickness50, 75, 100, 120, 150, 180, 200 mm
Maximum Service Temperature400 °C200 °C200 °C
