POLYURETHANE WALL PANEL | zdw insulation
Performance Features
- Energy-efficient Thermal Insulation: The core material features a closed-cell rate of up to 97%, offering superior thermal insulation performance that effectively reduces energy consumption.
- Fire Resistance and Flame Retardancy: Certified by authoritative national testing agencies; combustion performance complies with the GB8624 standard.
- Airtightness and Sound Insulation: Offers excellent sound absorption, reducing noise caused by rain and hail impacts.
- Eco-friendly: Formaldehyde-free, resistant to microbial growth, recyclable, and durable against corrosion and aging.
- Aesthetic and Cost-effective: Available in diverse profiles and a wide range of colors; lengths can be customized to reduce material waste and construction costs, enabling flexible and varied facade designs.
Technical Indicators（ Concealed fastened Wall Panel）
| Item | Parameter |
| Core Density | ≥40 kg/m³ |
| Compressive Strength | ≥150 KPa |
| Thermal Conductivity | ≤0.022 W/(m k) |
| Water Absorption | ＜3% |
| Flame Retardant Grade | Grade B1, B2 |
| Thickness mm | Heat Transfer Coefficient W/(m² k) | Weight(kg/m²) 0.5+0.4mm steel | Weight(kg/m²) 0.6+0.6mm steel |
| 50 | 0.47 | 9.90 | 11.73 |
| 75 | 0.32 | 10.60 | 12.78 |
| 100 | 0.24 | 12.00 | 14.18 |
